Offender Monitoring Tracker
Electronic Monitor for RF Ankle Bracelet
CO-EYE TRACKER is usually used with RF electronic ankle bracelets as two-pieces electronic monitoring device. Monitoring tracker has a high-performance ARM11 microprocessor with a main frequency of 1.7G and a 512M memory, which provides powerful data processing capabilities. It integrates multiple sensors and multi-mode radio frequency units on a dedicated embedded RTOS real-time operating system. High-security and high-reliability design for non-custodial control. It has passed a variety of safety tests and certifications including the safety protection products of the Ministry of Public Security, and has been widely used in the fields of judicial community correction, house arrest, bail, and furlough surveillance.
The main functions of monitoring tracker include all-weather electronic wristband scanning and monitoring; Beidou/GPS dual-mode satellite positioning; 3G/GPRS/SMS mobile data transmission; mobile base station assisted positioning; indoor WIFI assisted positioning; elevation/floor positioning; three-dimensional acceleration and electronics Motion state perception composed of compass; offline monitoring; large-capacity local data storage; integrated information two-way interaction, etc.
CO-EYE Monitoring Tracker Features
Precise positioning with multiple sensors
Supports Beidou/GPS satellite positioning, WIFI positioning, cell station positioning, inertial navigation positioning, RFID positioning and other multi-sensor data fusion, and has high anti-interference design such as anti-GPS satellite signal deception and pseudo base station deception. It has the capability of seamless roaming indoor and outdoor positioning, and the highly available location service capability with outdoor horizontal positioning accuracy of less than 3 meters, indoor horizontal positioning accuracy of less than 30 meters, and elevation positioning accuracy of less than 3 meters, providing a powerful way for the implementation of diverse electronic regulatory requirements Technical Support.
High sensitivity RF scan capability
The monitoring tracker adopts an ultra-high-sensitivity ISM band signal rapid scanning design, and the outdoor effective range of the ultra-low power electronic wristband is greater than 80 meters, and the indoor effective range penetrates 3 walls. Therefore, when the supervised object wearing the electronic wristband is in the home or work place, there is no need to carry the positioning terminal. Therefore, the split-type electronic supervision positioning terminal provides a complete supervision guarantee for residential surveillance, and also provides a more humane supervision experience for bail pending review or community corrections.
Continuous mobile supervision service capability
The CO-EYE tracker supports 3G/GPRS/SMS multiple mobile data networking capabilities, especially in areas with poor network coverage, which can still provide continuous mobile monitoring capabilities. Even if there is no network environment such as underground space, the positioning terminal can still provide offline supervision and cache the data until the network is restored and re-report the data.
Long battery life continuous working ability
When tracker adopts a 5-minute positioning frequency, high-precision positioning mode, and 21,600 electronic wristband scanning capabilities per day, a single charge provides continuous working time of more than 72 hours.
Zero-install with plug-and-play
The tracker provides a very flexible one-key configuration of composite sensors, without on-site engineering installation, plug-and-play support for different legal requirements for non-custodial control, including strict fixed-point control requirements for residential surveillance and mobile supervision for bail pending review/community corrections feature.
Expansion of acquisition and built-in storage capabilities
Tracker has a local data storage capacity of more than 4GB, provides a "black box" data logger function, and can cache all-element monitoring data for more than 1 year. At the same time, it can be extended to provide key additional data including wireless electromagnetic environment fingerprints, environmental voiceprints, such as WiFi, Bluetooth, mobile base stations, etc., to provide strong support for detection and data analysis in non-custodial control.
House Arrest Monitoring HouseStation
House Arrest Monitoring HouseStation is a wireless signal scanning enhanced version based on CO-EYE Tracker. It is mainly used for multi-floor residential surveillance and other specific applications, can provide seamless coverage monitoring of electronic ankle bracelet in complex villas building. Main features include:
- Inherited all functions of CO-EYE Tracker；
- It has the signal penetration ability to penetrate four concrete walls, and completes the seamless coverage monitoring of electronic ankle bracelet in complex villa environment；
- Built in dual card dual standby, support two-way telephone voice / SMS communication interaction ability；
- Built in large capacity backup battery, support 48 hours power off continuous monitoring；
- Support concurrent scanning and monitoring of multiple electronic bracelets or wristbands；
- Fully meet the high standard of House Arrest as a mandatory compliance of criminal justice.
